Radiogram Help

For additional information about traffic handling, consult The ARRL Operating Manual, published by ARRL,
or the NTS Methods and Practices Guidelines, Here

For additional information about traffic handling, consult the RRI Traffic-Operations-Manual, Here

1. NUMBER - Station of Origin's message number.  Use any number you want and only numbers. This is to identify the message through the NTS System. Never precede the number with a zero.


Emergency [EMERGENCY] Spell out in full (Life or death). Handle as quickly as possible.

Priority [P] - (Urgent). Handle after EMERGENCY traffic.

Welfare [W] - Inquiry or report as to health or welfare of an individual in the disaster area.

Routine [R] - (All other messages). Handle last.

3. HX

HXA followed by a number - Collect telephone delivery authorized by addressee within ______ miles. e.g. HXA100

HXB followed by a number - Cancel if not delivered within ______ hours of filing, and advise the originating station. e.g. HXB36

HXC - Report time and date of delivery to originating station.

HXD - Report to originating station identity of station from which received plus date and time. Report identity of station to which
relayed plus date and time. Report identify of station to which relayed, plus date and time, or if delivered report date,
time and method of delivery.

HXE - Delivering station to get reply from addressee, and originate message back to station of origin.

HXF followed by a number - Hold delivery until ______ (insert date). e.g. HXF/21

HXG - Delivery by mail or toll call not required. If toll or other expense involved, cancel and advise originating station.

4. STATION OF ORIGIN - This is the first station that wrote or helped write the message and bring to a NTS Net for relay.

5. CHECK -  This is the number of words or groups in the text message. Helps the receiving station to count the words in the text.
They must match the senders amount. If you use a ARRL numbered radiogram them put ARL before the check number.

6. PLACE OF ORIGIN - This is the actual place where the message started from, not necessarily the location of the Station of Origin.
For example if you originate a message for a person in a town that is not your own, use that person's own town.
Otherwise, use your own location.

7. TIME FILED - Time the message was written. Not necessary for Routine traffic but should be used for Emergency or Priority traffic.
Time should be UTC, not local time.

8. DATE - Date the message was written. Date should be correct for UTC time.


9. TO - Get complete information from person for whom you are sending the message. Name, and complete address are necessary to get the message to the right person as quickly as possible. Long zip codes are not necessary.

10. TELEPHONE NUMBER - If possible a number including area code should be included.


11. TEXT - The text is what the sender wants to tell the addressee, and should sound like a telegram - clear and concise and written so the meaning cannot be misconstrued. Text should be limited to 25 words and be NON-COMMERCIAL in nature. Phone numbers are broken into area code, exchange and number and are counted as three words. Periods are noted as X (X-Ray) and there is no X at the end of text. Each separator or X (X-ray) counts as 1 word. Closings such as “Love” and “Best Regards” are counted as words of text. When sending, a “Break” precedes and follows the text. If you have more than 25 words make 2 messages.


12. SIGNATURE - The signature identifies the person sending the message. As an OP Note, Additional identifying information may be added to the signature. Not counted in word count. As an example you could put the address and phone number for a message back to the message originator.
FSD-3    Relief Emergency · Routine Messages
Recommended Precedence

The letters ARL are inserted in the preamble in the check and in the text before spelled out numbers, which represent texts from this list. Note that some ARL texts include insertion of numerals and text.
For additional information about traffic handling, consult The ARRL Operating Manual, published by ARRL, or the NTS Methods and Practices Guidelines, .

Group One-For Possible "Relief Emergency" Use

ONE    Everyone safe here. Please don't worry.

TWO    Coming home as soon as possible.

THREE    Am in _____ hospital. Receiving excellent care and recovering fine.

FOUR    Only slight property damage here. Do not be concerned about disaster reports.

FIVE    Am moving to new location. Send no further mail or communication. Will inform you of new address when relocated.

SIX    Will contact you as soon as possible.

SEVEN    Please reply by Amateur Radio through the amateur delivering this message. This is a free public service.

EIGHT    Need additional _____ mobile or portable equipment for immediate emergency use.

NINE    Additional _____ radio operators needed to assist with emergency at this location.

TEN    Please contact _____. Advise to standby and provide further emergency information, instructions or assistance.

ELEVEN    Establish Amateur Radio emergency communications with _____ on _____ MHz.

TWELVE    Anxious to hear from you. No word in some time. Please contact me as soon as possible.

THIRTEEN    Medical emergency situation exits here.

FOURTEEN    Situation here becoming critical. Losses and damage from ____ increasing.

FIFTEEN    Please advise your condition and what help is needed.

SIXTEEN    Property damage very severe in this area.

SEVENTEEN    REACT communications services also available. Establish REACT communication with _____ on channel _____.

EIGHTEEN    Please contact me as soon as possible at _____.

NINETEEN    Request health and welfare report on _____ . (State name, address and telephone number.)

TWENTY    Temporarily stranded. Will need some assistance. Please contact me at _____.

TWENTY ONE    Search and Rescue assistance is needed by local authorities here. Advise availability.

TWENTY TWO    Need accurate information on the extent and type of conditions now existing at your location. Please furnish this information and reply without delay.

TWENTY THREE    Report at once the accessibility and best way to reach your location.

TWENTY FOUR    Evacuation of residents from this area urgently needed. Advise plans for help.

TWENTY FIVE    Furnish as soon as possible the weather conditions at your location.

TWENTY SIX    Help and care for evacuation of sick and injured from this location needed at once.

Emergency/priority messages originating from official sources must carry the signature of the originating official.

Group Two-Routine Messages

FORTY SIX    Greetings on your birthday and best wishes for many more to come.

FORTY SEVEN    Reference your message number _____ to _____ delivered on _____ at _____ UTC.

FIFTY    Greetings by Amateur Radio.

FIFTY ONE    Greetings by Amateur Radio. This message is sent as a free public service by ham radio operators at _____. Am having a wonderful time.

FIFTY TWO    Really enjoyed being with you. Looking forward to getting together again.

FIFTY THREE    Received your _____. It's appreciated; many thanks.

FIFTY FOUR    Many thanks for your good wishes.

FIFTY FIVE    Good news is always welcome. Very delighted to hear about yours.

FIFTY SIX    Congratulations on your _____, a most worthy and deserved achievement.

FIFTY SEVEN    Wish we could be together.

FIFTY EIGHT    Have a wonderful time. Let us know when you return.

FIFTY NINE    Congratulations on the new arrival. Hope mother and child are well.

*SIXTY    Wishing you the best of everything on _____.

SIXTY ONE    Wishing you a very Merry Christmas and a Happy New Year.

*SIXTY TWO    Greetings and best wishes to you for a pleasant _____ holiday season.

SIXTY THREE    Victory or defeat, our best wishes are with you. Hope you win.

SIXTY FOUR    Arrived safely at _____.

SIXTY FIVE    Arriving _____ on _____. Please arrange to meet me there.

SIXTY SIX    DX QSLs are on hand for you at the _____ QSL Bureau. Send _____ self addressed envelopes.

SIXTY SEVEN    Your message number _____ undeliverable because of _____. Please advise.

SIXTY EIGHT    Sorry to hear you are ill. Best wishes for a speedy recovery.

SIXTY NINE    Welcome to the _____. We are glad to have you with us and hope you will enjoy the fun and fellowship of the organization.

* Can be used for all holidays.

ARRL Recommended Precedences

Please observe the following ARRL provisions for PRECEDENCES in connection with written message traffic. These provisions are designed to increase the efficiency of our service both in normal times and in emergency.

EMERGENCY--Any message having life and death urgency to any person or group of persons, which is transmitted by Amateur Radio in the absence of regular commercial facilities. This includes official messages of welfare agencies during emergencies requesting supplies, materials or instructions vital to relief of stricken populace in emergency areas. During normal times, it will be very rare. On CW/RTTY, this designation will always be spelled out. When in doubt, do not use it.

PRIORITY--Use abbreviation P on CW/RTTY. This classification is for a) important messages having a specific time limit b) official messages not covered in the emergency category c) press dispatches and emergency-related traffic not of the utmost urgency d) notice of death or injury in a disaster area, personal or official.

WELFARE--This classification, abbreviated as W on CW/RTTY, refers to either an inquiry as to the health and welfare of an individual in the disaster area or an advisory from the disaster area that indicates all is well. Welfare traffic is handled only after all emergency and priority traffic is cleared. The Red Cross equivalent to an incoming Welfare message is DWI (Disaster Welfare Inquiry).

ROUTINE--Most traffic in normal times will bear this designation. In disaster situations, traffic labeled Routine (R on CW/RTTY) should be handled last, or not at all when circuits are busy with higher precedence traffic.

Note--the precedence always follows the message number. For example, a message number may be 207R on CW and "Two Zero Seven Routine" on phone.
State of Orgin
Place of Orgin
Time Filed
Numbers In Boxes Corresponds With Preamble Instructions Below
Interactive Radiogram
Just click and type in each section when finished or would like to practice some more just click the clear Radiogram button bellow
